Applications
Rubber profile drilling machine is used to drill vent holes with different spacing on the rubber strip according to the process requirements.
Features
| Line Speed | Max. 35m/min |
| Speed control | Ultrasonic speed control mechanism |
| Pulling Method | Belt puller |
| Drilling Device | 1 set, vertical drilling |
| Drilling Motor | Servo motor |
| Drill | Pneumatic or electric drill optional |
| Drill Diameter | ∮3mm |
| Drilling Speed | When using 4 drills with a hole spacing of 100mm, the max. speed is 30m/min. |
| Hole spacing | 100～300mm, adjustable |
| Alarm | Sound-light alarm for abnormal servo motor and motor drive |
| Safety protection | Overall protection for the drilling and pulling parts |
| Dimensions | L1420×W1850×H850mm (subject to final design drawings) |
| Drive Power | 0.75kW |
| Speed Control | Photoelectric |
| Line Speed | 2～25m/min, frequency conversion speed control |
| Traction Method | Belt puller (simple protection) |
| Number of Air Drills | 6 |
| Drill Diameter | ⌀3mm |
As a professional manufacturer of rubber equipment, Julong not only offers a wide range of individual machines but also provides customized production lines to meet various production needs for rubber seals and profiles.
Julong provides a wide range of rubber extrusion lines designed for the production of rubber seals and profiles with various shapes and sizes, suitable for customers who require high production speed, advanced technology, and excellent material quality. The production line can be customized with various equipment according to customer needs.
Julong provides a specialized rubber co-extrusion line, designed for the production of various types of composite rubber profiles. It is suitable for customers who require high production speed, advanced technology, and excellent material quality. The production line can be customized with various equipment options according to customer needs.
Julong provides professional electrostatic flocking lines for the flocking process on rubber, which is suitable for customers who require a high production speed, advanced technology, and excellent material quality. The production line can be customized with various equipment options according to customer needs.
Julong provides rubber coating line for rubber surface coating. Excellent coating can effectively enhance the material properties of the rubber surface, making it suitable for subsequent processing. This is ideal for customers who require high production speed, advanced technology, and excellent material quality.
